Configuration
5-26 7SA522 Manual
C53000-G1176-C119-2
Select one of the following options for the named indication types:
• 2 (on or coming) – the indication is stored in the buffer with the time of its arrival
• 22 (on/off or coming/going) – the indication is stored in the buffer with the time of
its arrival and departure
• B (not configured) – the indication is not stored in a buffer.
Configuring CFC
as a Destination
Single point, double point, and output indications, as well as limit and measured val-
ues, may be configured to CFC as the destination.
Configuring the
Measured Value
Window as a Desti-
nation
In addition to the measured values available in the relay, user defined measured and
limit values may be configured into the measured value window. These values also
become available in the device display in the assigned measurement window.
Table 5-2 Overview of Indication Buffers
Information Type ↓ \Message Buffer → OT
Single Point Indications (SP) X X
Double Point Indications (DP) X
Output Indications (OUT) X X
Internal Single Point Indications (IntSP) X X
Internal Double Point Indications (DP) X
Table 5-3 Overview of indications via the system interface
Information Type ↓ \Message Buffer → IEC
Single Point Indications (SP) X
Double Point Indications (DP)
Output Indications (OUT) X
Internal Single Point Indications (IntSP) X
Internal Double Point Indications (DP) X
Command with/without feedback (C_**) X
Measurement value
Measurement value with time (MVT)
Measurement value, user defined (MVU)
Impulse counting value (ICV)
Warning!
CFC connection have to be reestablished after renaming of a display text of an user
defined information. Within the CFC the old name is shown at the left column. Delete
this connection. Make connection to the desired blocks using the renamed informa-
tion.
