Siemens siprotec 7SA522 User Manual

Appendix
B-13
7SA522 Manual
C53000-G1176-C119-2
3210 TrBlk BlockTime Teleprotection for
Earth fault overcurr.
0.00..30.00 sec 0.05 sec Transient Block.: Blk.T. after ext. flt.
3401 AUTO RECLOSE Automatic Reclo-
sure
OFF
ON
ON Auto-Reclose function
3402 CB? 1.TRIP Automatic Reclo-
sure
YES
NO
NO CB ready interrogation at 1st trip
3403 T-RECLAIM Automatic Reclo-
sure
0.50..300.00 sec 3.00 sec Reclaim (Reset) time after AR
3404 T-BLOCK MC Automatic Reclo-
sure
0.50..300.00 sec 1.00 sec AR blocking duration after manual
close
3406 EV. FLT. RECOG. Automatic Reclo-
sure
with Pickup
with Trip
with Trip Evolving fault recognition
3407 EV. FLT. MODE Automatic Reclo-
sure
blocks AR
starts 3pole AR-cycle
starts 3pole AR-cycle Evolving fault (during the dead time)
3408 T-Start MONITOR Automatic Reclo-
sure
0.01..300.00 sec 0.50 sec AR start-signal monitoring time
3409 CB TIME OUT Automatic Reclo-
sure
0.01..300.00 sec 3.00 sec Circuit Breaker (CB) Supervision Time
3410 T RemoteClose Automatic Reclo-
sure
0.00..300.00 sec
∞ sec
Send delay for remote close command
3411 T-DEAD EXT. Automatic Reclo-
sure
0.50..300.00 sec
∞ sec
Maximum dead time extension
3420 AR w/ DIST. Automatic Reclo-
sure
YES
NO
YES AR with distance protection
3421 AR w/ SOTF-O/C Automatic Reclo-
sure
YES
NO
YES AR with switch-onto-fault overcurrent
3422 AR w/ W/I Automatic Reclo-
sure
YES
NO
YES AR with weak infeed tripping
3423 AR w/ EF-O/C Automatic Reclo-
sure
YES
NO
YES AR with earth fault overcurrent prot.
3424 AR w/ DTT Automatic Reclo-
sure
YES
NO
YES AR with direct transfer trip
3425 AR w/ BackUpO/C Automatic Reclo-
sure
YES
NO
YES AR with back-up overcurrent
3430 AR TRIP 3pole Automatic Reclo-
sure
YES
NO
NO 3pole TRIP by AR
3431 DLC or RDT Automatic Reclo-
sure
Without
Reduced Dead Time (RDT)
Dead Line Check (DLC)
Without Dead Line Check or Reduced Dead
Time
3433 T-ACTION ADT Automatic Reclo-
sure
0.01..300.00 sec 0.20 sec Action time
3434 T-MAX ADT Automatic Reclo-
sure
0.50..3000.00 sec 5.00 sec Maximum dead time
3435 ADT 1p allowed Automatic Reclo-
sure
YES
NO
NO 1pole TRIP allowed
3436 ADT CB? CLOSE Automatic Reclo-
sure
YES
NO
NO CB ready interrogation before reclos-
ing
3437 ADT SynRequest Automatic Reclo-
sure
YES
NO
NO Request for synchro-check after 3pole
AR
3438 T U-stable Automatic Reclo-
sure
0.10..30.00 sec 0.10 sec Supervision time for dead/ live voltage
3438 T U-stable Automatic Reclo-
sure
0.10..30.00 sec 0.10 sec Supervision time for dead/ live voltage
3440 U-live> Automatic Reclo-
sure
30..90 V 48 V Voltage threshold for live line or bus
3440 U-live> Automatic Reclo-
sure
30..90 V 48 V Voltage threshold for live line or bus
