Siemens siprotec 7SA522 User Manual

Appendix
B-14
3441 U-dead< Automatic Reclo-
sure
2..70 V 30 V Voltage threshold for dead line or bus
3450 1.AR: START Automatic Reclo-
sure
YES
NO
YES Start of AR allowed in this cycle
3451 1.AR: T-ACTION Automatic Reclo-
sure
0.01..300.00 sec 0.20 sec Action time
3452 1.AR 1p allowed Automatic Reclo-
sure
YES
NO
NO 1pole TRIP allowed
3453 1.AR Tdead 1Flt Automatic Reclo-
sure
0.01..1800.00 sec 1.20 sec Dead time after 1phase faults
3454 1.AR Tdead 2Flt Automatic Reclo-
sure
0.01..1800.00 sec 1.20 sec Dead time after 2phase faults
3455 1.AR Tdead 3Flt Automatic Reclo-
sure
0.01..1800.00 sec 0.50 sec Dead time after 3phase faults
3456 1.AR Tdead1Trip Automatic Reclo-
sure
0.01..1800.00 sec 1.20 sec Dead time after 1pole trip
3457 1.AR Tdead3Trip Automatic Reclo-
sure
0.01..1800.00 sec 0.50 sec Dead time after 3pole trip
3458 1.AR: Tdead EV. Automatic Reclo-
sure
0.01..1800.00 sec 1.20 sec Dead time after evolving fault
3459 1.AR: CB? CLOSE Automatic Reclo-
sure
YES
NO
NO CB ready interrogation before reclos-
ing
3460 1.AR SynRequest Automatic Reclo-
sure
YES
NO
NO Request for synchro-check after 3pole
AR
3461 2.AR: START Automatic Reclo-
sure
YES
NO
NO AR start allowed in this cycle
3462 2.AR: T-ACTION Automatic Reclo-
sure
0.01..300.00 sec 0.20 sec Action time
3463 2.AR 1p allowed Automatic Reclo-
sure
YES
NO
NO 1pole TRIP allowed
3464 2.AR Tdead 1Flt Automatic Reclo-
sure
0.01..1800.00 sec 1.20 sec Dead time after 1phase faults
3465 2.AR Tdead 2Flt Automatic Reclo-
sure
0.01..1800.00 sec 1.20 sec Dead time after 2phase faults
3466 2.AR Tdead 3Flt Automatic Reclo-
sure
0.01..1800.00 sec 0.50 sec Dead time after 3phase faults
3467 2.AR Tdead1Trip Automatic Reclo-
sure
0.01..1800.00 sec 1.20 sec Dead time after 1pole trip
3468 2.AR Tdead3Trip Automatic Reclo-
sure
0.01..1800.00 sec 0.50 sec Dead time after 3pole trip
3469 2.AR: Tdead EV. Automatic Reclo-
sure
0.01..1800.00 sec 1.20 sec Dead time after evolving fault
3470 2.AR: CB? CLOSE Automatic Reclo-
sure
YES
NO
NO CB ready interrogation before reclos-
ing
3471 2.AR SynRequest Automatic Reclo-
sure
YES
NO
NO Request for synchro-check after 3pole
AR
3472 3.AR: START Automatic Reclo-
sure
YES
NO
NO AR start allowed in this cycle
3473 3.AR: T-ACTION Automatic Reclo-
sure
0.01..300.00 sec 0.20 sec Action time
3474 3.AR 1p allowed Automatic Reclo-
sure
YES
NO
NO 1pole TRIP allowed
3475 3.AR Tdead 1Flt Automatic Reclo-
sure
0.01..1800.00 sec 1.20 sec Dead time after 1phase faults
3476 3.AR Tdead 2Flt Automatic Reclo-
sure
0.01..1800.00 sec 1.20 sec Dead time after 2phase faults
Addr. Setting Title Function Setting Options Default Setting Comments
