Appendix
B-19
7SA522 Manual
C53000-G1176-C119-2
140 Error with a summary alarm (Error
Sum Alarm)
Device OUT * * LED BO 128 47 1 GI
144 Error 5V (Error 5V) Device OUT ON
OFF
* LED BO 135 164 1 GI
160 Alarm Summary Event (Alarm Sum
Event)
Device OUT * * LED BO 128 46 1 GI
161 Failure: General Current Supervision
(Fail I Superv.)
Measure-
ment Supervi-
sion
OUT * * LED BO 128 32 1 GI
162 Failure: Current Summation (Failure
Σ I)
Measure-
ment Supervi-
sion
OUT ON
OFF
* LED BO 135 182 1 GI
163 Failure: Current Balance (Fail I bal-
ance)
Measure-
ment Supervi-
sion
OUT ON
OFF
* LED BO 135 183 1 GI
164 Failure: general Voltage Supervision
(Fail U Superv.)
Measure-
ment Supervi-
sion
OUT * * LED BO 128 33 1 GI
165 Failure: Voltage summation Phase-
Earth (Fail Σ U Ph-E)
Measure-
ment Supervi-
sion
OUT ON
OFF
* LED BO 135 184 1 GI
167 Failure: Voltage Balance (Fail U bal-
ance)
Measure-
ment Supervi-
sion
OUT ON
OFF
* LED BO 135 186 1 GI
169 VT Fuse Failure (alarm >10s) (VT
FuseFail>10s)
Measure-
ment Supervi-
sion
OUT ON
OFF
* LED BO 135 188 1 GI
170 VT Fuse Failure (alarm instanta-
neous) (VT FuseFail)
Measure-
ment Supervi-
sion
OUT ON
OFF
* LED BO
171 Failure: Phase Sequence (Fail Ph.
Seq.)
Measure-
ment Supervi-
sion
OUT ON
OFF
* LED BO 128 35 1 GI
177 Failure: Battery empty (Fail Battery) Device OUT ON
OFF
* LED BO 135 193 1 GI
181 Error: A/D converter (Error A/D-
conv.)
Device OUT ON
OFF
* LED BO 135 178 1 GI
182 Alarm: Real Time Clock (Alarm
Clock)
Device OUT ON
OFF
* LED BO 135 194 1 GI
183 Error Board 1 (Error Board 1) Device OUT ON
OFF
* LED BO 135 171 1 GI
184 Error Board 2 (Error Board 2) Device OUT ON
OFF
* LED BO 135 172 1 GI
185 Error Board 3 (Error Board 3) Device OUT ON
OFF
* LED BO 135 173 1 GI
186 Error Board 4 (Error Board 4) Device OUT ON
OFF
* LED BO 135 174 1 GI
187 Error Board 5 (Error Board 5) Device OUT ON
OFF
* LED BO 135 175 1 GI
188 Error Board 6 (Error Board 6) Device OUT ON
OFF
* LED BO 135 176 1 GI
F.No. Description Function Type of Infor-
mation
Log-Buffers Configurable in Matrix IEC 60870-5-103
Event Log On/Off
Trip (Fault) Log On/Off
Ground Fault Log On/Off
Marked in Oscill. Record
LED
Binary Input
Function Key
Binary Output
Event Log
Type
Information-No
Data Unit (ASDU)
General Interrogation
To Next Page
