Appendix
B-20
189 Error Board 7 (Error Board 7) Device OUT ON
OFF
* LED BO 135 177 1 GI
190 Error Board 0 (Error Board 0) Device OUT ON
OFF
* LED BO 135 210 1 GI
192 Error:1A/5Ajumper different from set-
ting (Error1A/5Awrong)
Device OUT ON
OFF
* LED BO 135 169 1 GI
193 Alarm: NO calibration data available
(Alarm NO calibr)
Device OUT ON
OFF
* LED BO 135 181 1 GI
194 Error: Neutral CT different from
MLFB (Error neutralCT)
Device OUT ON
OFF
* LED BO 135 180 1 GI
195 Failure: Broken Conductor (Fail Con-
ductor)
Measure-
ment Supervi-
sion
OUT ON
OFF
* LED BO 135 195 1 GI
196 Fuse Fail Monitor is switched OFF
(Fuse Fail M.OFF)
Measure-
ment Supervi-
sion
OUT ON
OFF
* LED BO 135 196 1 GI
197 Measurement Supervision is
switched OFF (MeasSup OFF)
Measure-
ment Supervi-
sion
OUT ON
OFF
* LED BO 135 197 1 GI
203 Waveform data deleted (Wave.
deleted)
Oscillo-
graphic Fault
Records
OUT_Ev ON * LED BO 135 203 1
351 >Circuit breaker aux. contact: Pole
L1 (>CB Aux. L1)
Power Sys-
tem Data 2
SP * * LED BI BO 150 1 1 GI
352 >Circuit breaker aux. contact: Pole
L2 (>CB Aux. L2)
Power Sys-
tem Data 2
SP * * LED BI BO 150 2 1 GI
353 >Circuit breaker aux. contact: Pole
L3 (>CB Aux. L3)
Power Sys-
tem Data 2
SP * * LED BI BO 150 3 1 GI
356 >Manual close signal (>Manual
Close)
Power Sys-
tem Data 2
SP * * LED BI BO 150 6 1 GI
357 >Block all Close commands from
external (>Close Cmd. Blk)
Power Sys-
tem Data 2
SP ON
OFF
* LED BI BO 150 7 1 GI
361 >Failure: Feeder VT (MCB tripped)
(>FAIL:Feeder VT)
Power Sys-
tem Data 2
SP ON
OFF
* LED BI BO 128 38 1 GI
362 >Failure: Busbar VT (MCB tripped)
(>FAIL:Bus VT)
Power Sys-
tem Data 2
SP ON
OFF
* LED BI BO 150 12 1 GI
366 >CB1 Pole L1 (for AR,CB-Test)
(>CB1 Pole L1)
Power Sys-
tem Data 2
SP * * LED BI BO 150 66 1 GI
367 >CB1 Pole L2 (for AR,CB-Test)
(>CB1 Pole L2)
Power Sys-
tem Data 2
SP * * LED BI BO 150 67 1 GI
368 >CB1 Pole L3 (for AR,CB-Test)
(>CB1 Pole L3)
Power Sys-
tem Data 2
SP * * LED BI BO 150 68 1 GI
371 >CB1 READY (for AR,CB-Test)
(>CB1 Ready)
Power Sys-
tem Data 2
SP * * LED BI BO 150 71 1 GI
378 >CB faulty (>CB faulty) Power Sys-
tem Data 2
SP * * LED BI BO
379 >CB aux. contact 3pole Closed (>CB
3p Closed)
Power Sys-
tem Data 2
SP * * LED BI BO 150 78 1 GI
F.No. Description Function Type of Infor-
mation
Log-Buffers Configurable in Matrix IEC 60870-5-103
Event Log On/Off Trip (Fault) Log On/Off Ground Fault Log On/Off Marked in Oscill. Record LED Binary Input Function Key Binary Output Event Log Type Information-No Data Unit (ASDU) General Interrogation
