Appendix
B-21
7SA522 Manual
C53000-G1176-C119-2
380 >CB aux. contact 3pole Open (>CB
3p Open)
Power Sys-
tem Data 2
SP * * LED BI BO 150 79 1 GI
381 >Single-phase trip permitted from
ext.AR (>1p Trip Perm)
Power Sys-
tem Data 2
SP ON
OFF
* LED BI BO
382 >External AR programmed for
1phase only (>Only 1ph AR)
Power Sys-
tem Data 2
SP ON
OFF
* LED BI BO
383 >Enable all AR Zones / Stages
(>Enable ARzones)
Power Sys-
tem Data 2
SP ON
OFF
ON
OFF
LED BI BO
385 >Lockout SET (>Lockout SET) Power Sys-
tem Data 2
SP ON
OFF
* LED BI BO 150 35 1 GI
386 >Lockout RESET (>Lockout RESET) Power Sys-
tem Data 2
SP ON
OFF
* LED BI BO 150 36 1 GI
410 >CB1 aux. 3p Closed (for AR, CB-
Test) (>CB1 3p Closed)
Power Sys-
tem Data 2
SP * * LED BI BO 150 80 1 GI
411 >CB1 aux. 3p Open (for AR, CB-
Test) (>CB1 3p Open)
Power Sys-
tem Data 2
SP * * LED BI BO 150 81 1 GI
501 Relay PICKUP (Relay PICKUP) Power Sys-
tem Data 2
OUT * * M LED BO 128 84 2 GI
503 Relay PICKUP Phase L1 (Relay
PIKKUP L1)
Power Sys-
tem Data 2
OUT * * M LED BO 128 64 2 GI
504 Relay PICKUP Phase L2 (Relay
PIKKUP L2)
Power Sys-
tem Data 2
OUT * * M LED BO 128 65 2 GI
505 Relay PICKUP Phase L3 (Relay
PIKKUP L3)
Power Sys-
tem Data 2
OUT * * M LED BO 128 66 2 GI
506 Relay PICKUP Earth (Relay PICKUP
E)
Power Sys-
tem Data 2
OUT * * M LED BO 128 67 2 GI
507 Relay TRIP command Phase L1
(Relay TRIP L1)
Power Sys-
tem Data 2
OUT * * M LED BO 128 69 2
508 Relay TRIP command Phase L2
(Relay TRIP L2)
Power Sys-
tem Data 2
OUT * * M LED BO 128 70 2
509 Relay TRIP command Phase L3
(Relay TRIP L3)
Power Sys-
tem Data 2
OUT * * M LED BO 128 71 2
510 Relay GENERAL CLOSE command
(Relay CLOSE)
Power Sys-
tem Data 2
OUT * * * LED BO 128 128 1
511 Relay GENERAL TRIP command
(Relay TRIP)
Power Sys-
tem Data 2
OUT *
OFF
M LED BO 128 68 2
512 Relay TRIP command - Only Phase
L1 (Relay TRIP 1pL1)
Power Sys-
tem Data 2
OUT * * LED BO
513 Relay TRIP command - Only Phase
L2 (Relay TRIP 1pL2)
Power Sys-
tem Data 2
OUT * * LED BO
514 Relay TRIP command - Only Phase
L3 (Relay TRIP 1pL3)
Power Sys-
tem Data 2
OUT * * LED BO
515 Relay TRIP command Phases L123
(Relay TRIP 3ph.)
Power Sys-
tem Data 2
OUT * * LED BO
530 LOCKOUT is active (LOCKOUT) Power Sys-
tem Data 2
IntSP ON
OFF
ON
OFF
LED BO 150 170 1 GI
533 Primary fault current IL1 (IL1 =) Power Sys-
tem Data 2
OUT * ON
OFF
150 177 4
F.No. Description Function Type of Infor-
mation
Log-Buffers Configurable in Matrix IEC 60870-5-103
Event Log On/Off Trip (Fault) Log On/Off Ground Fault Log On/Off Marked in Oscill. Record LED Binary Input Function Key Binary Output Event Log Type Information-No Data Unit (ASDU) General Interrogation
