Appendix
B-22
534 Primary fault current IL2 (IL2 =) Power Sys-
tem Data 2
OUT * ON
OFF
150 178 4
535 Primary fault current IL3 (IL3 =) Power Sys-
tem Data 2
OUT * ON
OFF
150 179 4
536 Relay Definitive TRIP (Definitive
TRIP)
Power Sys-
tem Data 2
OUT ON ON * LED BO 150 180 2
545 Time from Pickup to drop out (PU
Time)
Power Sys-
tem Data 2
OUT
546 Time from Pickup to TRIP (TRIP
Time)
Power Sys-
tem Data 2
OUT
560 Single-phase trip was coupled
3phase (Trip Coupled 3p)
Power Sys-
tem Data 2
OUT * ON LED BO 150 210 2
561 Manual close signal detected
(Man.Clos.Detect)
Power Sys-
tem Data 2
OUT ON * LED BO 150 211 1
562 CB CLOSE command for manual
closing (Man.Close Cmd)
Power Sys-
tem Data 2
OUT * * LED BO 150 212 1
563 CB alarm suppressed (CB Alarm
Supp)
Power Sys-
tem Data 2
OUT ON ON * LED BO
601 I L1 (IL1 =) Measurement MV 128
134
148
124
3
9
602 I L2 (IL2 =) Measurement MV 128
134
148
124
3
9
603 I L3 (IL3 =) Measurement MV 128
134
148
124
3
9
610 3I0 (zero sequence) (3I0 =) Measurement MV
611 3I0sen (sensitive zero sequence)
(3I0sen=)
Measurement MV
612 IY (star point of transformer) (IY =) Measurement MV
613 3I0par (parallel line neutral)
(3I0par=)
Measurement MV
619 I1 (positive sequence) (I1 =) Measurement MV
620 I2 (negative sequence) (I2 =) Measurement MV
621 U L1-E (UL1E=) Measurement MV 128
134
148
124
3
9
622 U L2-E (UL2E=) Measurement MV 128
134
148
124
3
9
623 U L3-E (UL3E=) Measurement MV 128
134
148
124
3
9
624 U L12 (UL12=) Measurement MV 128
134
148
124
3
9
625 U L23 (UL23=) Measurement MV 128
134
148
124
3
9
626 U L31 (UL31=) Measurement MV 128
134
148
124
3
9
631 3U0 (zero sequence) (3U0 =) Measurement MV
632 Usync (synchronism) (Usync =) Measurement MV
F.No. Description Function Type of Infor-
mation
Log-Buffers Configurable in Matrix IEC 60870-5-103
Event Log On/Off
Trip (Fault) Log On/Off
Ground Fault Log On/Off
Marked in Oscill. Record
LED
Binary Input
Function Key
Binary Output
Event Log
Type
Information-No
Data Unit (ASDU)
General Interrogation
