Appendix
B-27
7SA6 Manual
C53000-G1176-C156-2
402 >Q MIN/MAX Buffer Reset (>Q MiMa
Reset)
Min/Max Mea-
surement Setup
SP ON * LED BI BO
403 >Idmd MIN/MAX Buffer Reset (>Idmd
MiMaReset)
Min/Max Mea-
surement Setup
SP ON * LED BI BO
404 >Pdmd MIN/MAX Buffer Reset (>Pdmd
MiMaReset)
Min/Max Mea-
surement Setup
SP ON * LED BI BO
405 >Qdmd MIN/MAX Buffer Reset (>Qdmd
MiMaReset)
Min/Max Mea-
surement Setup
SP ON * LED BI BO
406 >Sdmd MIN/MAX Buffer Reset (>Sdmd
MiMaReset)
Min/Max Mea-
surement Setup
SP ON * LED BI BO
407 >Frq. MIN/MAX Buffer Reset (>Frq MiMa
Reset)
Min/Max Mea-
surement Setup
SP ON * LED BI BO
408 >Power Factor MIN/MAX Buffer Reset
(>PF MiMaReset)
Min/Max Mea-
surement Setup
SP ON * LED BI BO
410 >CB1 aux. 3p Closed (for AR, CB-Test)
(>CB1 3p Closed)
Power System
Data 2
SP * * LED BI BO 150 80 1 GI
411 >CB1 aux. 3p Open (for AR, CB-Test)
(>CB13pOpen)
Power System
Data 2
SP * * LED BI BO 150 81 1 GI
501 Relay PICKUP (Relay PICKUP) Power System
Data 2
OUT * * M LED BO 128 84 2 GI
503 Relay PICKUP Phase L1 (Relay PIKKUP
L1)
Power System
Data 2
OUT * * M LED BO 128 64 2 GI
504 Relay PICKUP Phase L2 (Relay PIKKUP
L2)
Power System
Data 2
OUT * * M LED BO 128 65 2 GI
505 Relay PICKUP Phase L3 (Relay PIKKUP
L3)
Power System
Data 2
OUT * * M LED BO 128 66 2 GI
506 Relay PICKUP Earth (Relay PICKUP E) Power System
Data 2
OUT * * M LED BO 128 67 2 GI
507 Relay TRIP command Phase L1 (Relay
TRIP L1)
Power System
Data 2
OUT * * M LED BO 128 69 2
508 Relay TRIP command Phase L2 (Relay
TRIP L2)
Power System
Data 2
OUT * * M LED BO 128 70 2
509 Relay TRIP command Phase L3 (Relay
TRIP L3)
Power System
Data 2
OUT * * M LED BO 128 71 2
510 Relay GENERAL CLOSE command
(Relay CLOSE)
Power System
Data 2
OUT * * * LED BO
511 Relay GENERAL TRIP command (Relay
TRIP)
Power System
Data 2
OUT *
OFF
M LED BO 128 68 2
512 Relay TRIP command - Only Phase L1
(Relay TRIP 1pL1)
Power System
Data 2
OUT * * LED BO
513 Relay TRIP command - Only Phase L2
(Relay TRIP 1pL2)
Power System
Data 2
OUT * * LED BO
514 Relay TRIP command - Only Phase L3
(Relay TRIP 1pL3)
Power System
Data 2
OUT * * LED BO
515 Relay TRIP command Phases L123
(Relay TRIP 3ph.)
Power System
Data 2
OUT * * LED BO
530 LOCKOUT is active (LOCKOUT) Power System
Data 2
IntSP ON
OFF
ON
OFF
LED BO 150 170 1 GI
F.No. Description Function Type of
Informa-
tion
Log-Buffers Configurable in Matrix IEC 60870-5-103
Event Log On/Off Trip (Fault) Log On/Off Ground Fault Log On/Off Marked in Oscill. Record LED Binary Input Function Key Binary Output Chatter Blocking Type Information-No Data Unit (ASDU) General Interrogation
