Table 4-4 Configuration of a double busbar with combi-bus
Bay:
(xx)
Bay Type ISO.1:Axx ISO.2:Axx ISO.3:Axx ISO.4:Axx ISO.5:Axx CT LOC
01 1-bay cou-
pler
CL-BZ1 CR-BZ4 not existent not existent not existent Bus side t. line
02 Feeder bay BZ1 BZ4 not existent BZ4 not existent line side
03 Feeder bay BZ1 BZ4 not existent BZ4 not existent line side
04 1-bay cou-
pler
w/o CB
CL-BZ4 CR-BZ5 not existent not existent not existent Bus side t. bus
05 Section iso-
lator
BZ1/BZ2 not existent not existent not existent not existent non existent
06 1-bay cou-
pler
CL-BZ2 CR-BZ5 not existent not existent not existent Bus side t. bus
07 Feeder bay BZ2 BZ5 not existent BZ5 not existent line side
08 Section iso-
lator
BZ2/BS1 BZ5/BS2 not existent not existent not existent non existent
09 1-bay cou-
pler
CL-BS1 CR-BS2 not existent not existent not existent Bus side t. line
10 Section iso-
lator
BS1/BZ3 BS2/BZ6 not existent not existent not existent non existent
11 Feeder bay BZ3 BZ6 not existent BZ6 not existent line side
12 Feeder bay BZ3 BZ6 not existent BZ6 not existent line side
