Siemens SIPROTEC 7SS523 V3.2

Parameter Listing - Bay Unit
359
7SS52 V4 Manual
C53000-G1176-C182-1
5701 IL1[%] = Current in phase L1 [%] =
5702 IL2[%] = Current in phase L2 [%] =
5703 IL3[%] = Current in phase L3 [%] =
5704 IE[%] = IE[%] =
5705 IL1 = Current in phase L1 =
5706 IL2 = Current in phase L2 =
5707 IL3 = Current in phase L3 =
5708 IE a = Operational measurement: IEa=
5709 IL1 = Normalized current IL1 =
5710 IL2 = Normalized current IL2 =
5711 IL3 = Normalized current IL3 =
5712 IE = Normalized current IE =
5713 IDL1[%]= BZ: Differential current phase L1
[%] =
5714 IDL2[%]= BZ: Differential current phase L2
[%] =
5715 IDL3[%]= BZ: Differential current phase L3
[%] =
5716 ISL1[%]= BZ: Stabilising current phase L1 [%]
=
5717 ISL2[%]= BZ: Stabilising current phase L2 [%]
=
5718 ISL3[%]= BZ: Stabilising current phase L3 [%]
=
5719 f [Hz]= Frequency f [Hz] =
3912 B.U.CBF-T Back-Up
Break.Fail.Prot.
0.06..60.00 s; +* 0.12 s Time delay of back-up breaker fail-
ure prot.
6101 BINARY INPUT 1 Marshalling Binary input 1
... ... ... ...
6120 BINARY INPUT 20 Marshalling Binary input 20
6201 SIGNAL RELAY 1 Marshalling Signal relay 1
6301 LED 1 Marshalling LED 1
... ... ... ...
6316 LED 16 Marshalling LED 16
6401 TRIP RELAY 1 Marshalling Trip relay 1
... ... ... ...
6405 TRIP RELAY 5 Marshalling Trip relay 5
7101 Language Integrated Opera-
tion
DEUTSCH
ENGLISH
FRANCAIS
ESPANOL
ITALIANO
PYCCK.
ENGLISH Language
Addr. Setting Title Function Setting Options Default Setting Comments
