Appendix
364
7SS52 V4 Manual
C53000-G1176-C182-1
Column ”Type“ (Function Bay Unit): Informationen that belong to the bay units are
of types 195 to 206. In these types up to 256 information numbers can be addressed.
These types are divided into 4 blocks each with 63 information numbers each. The
blocks are assigned to the bay units. The basic type number is given in brackets.
Example:
The effective information number of each type number can be calculated with the fol-
lowing formula:
x = 63 ∗ (n - 1) + m
Column ”Information number“: The basic information number is given in brackets.
Bay Unit
No. n
Information
Number m
Type Effective Information
Number x
111195 1
... ...
63 63
221195 64
... ...
63 126
3 3 1 195 127
... ...
63 189
4 4 1 195 190
... ...
63 252
511196 1
... ...
63 63
... ... ... ... ...
8 4 1 196 190
... ...
63 252
... ... ... ... ...
48 4 1 206 190
... ...
63 252
Note
Only the annuciations subject to general interrogation are reported as ON/OFF to the
IEC 60870-5-103 interface. Indications that are not subject to general interrogation are
only reported as ON.
