Configuring the hardware
The next thing to do is to update the UPS1600 in the hardware configuration.
Proceed as follows:
1. Drag the UPS1600 from the device catalog (1) onto the PROFINET IO system
of the AS.
2. Open the properties of the DC UPS and enter the device name (2) and the

Figure 5-3
1
2
3
