4.5.3 Channel 5 and 6 input con󹪝guration
Note
Connection of optional devices
The external DSL provides the option of connecting two additional devices to channels 5 and 6.
Do not connect two devices to one channel.
Note
Analog input on channel 6
Hardware version 2 and below does not support analog input on channel 6.
Input con󹪝guration
Connect the two, three or four wires to the terminal block as shown below. Short-circuit
terminals as required.
Note
The terminal connector is detachable
For easier access unplug the terminal connector. After connecting the wires, plug the terminal
connector back in.
Note
RTD shield grounding
Make sure that the RTD cable shield is properly grounded. Consult the FSS200 Installation
Manual on how to ground the RTD cable shield.
Connecting
4.5Connecting the external DSL
SITRANS FS130 & FS230
48 Compact Operating Instructions, 12/2023, A5E38755607-AF
