Commands
SIWAREX FTA
6-129
Code
Command explanation
Executable
in following
operating
states
15
Characteristic curve shift
The instruction shifts the entire characteristic curve
(adjustment coordinates) so that the current filtered
digital value from the ADC is made into a zero
point. Only permitted with a calibration switch that
is not set. If an impermissible digital value results
from the shift then the instruction is rejected.
Service
operation
Scale commands
21
Zeroing
The current weight is set to zero. In calibratable
operation (“OIML”), only possible with restrictions
(-1%, +3%). The tare is deleted at the same time.
No weighing
cycle, Service
operation
22
Tare
The current weight is set to zero and the weight
display is designated as “Net” and “Tare” at the
same time.
No weighing
cycle
23
Delete tare
The tare is deleted. The current weight is displayed
and designations of “Net” are changed to “Gross”,
the designation “Tare” or “Preset-Tare” is reset.
No weighing
cycle
24
Accept tare entry
The defined tare is accepted as tare and at the
same time, “Preset tare” is designated together
with the weight display.
No weighing
cycle
25
Switch on increased resolution
Activate output / display of the calibratable weight
value with increased resolution for 5 seconds.
All
26
Display tare weight
Activate output / display of the tare value for 5
seconds.
All
29
Display firmware
Displays the firmware version in the DR34 for 5
seconds
All
