Service Protocol
AG05 Date: 15.06.2016 Art. No. 85677 Mod. status 139/16 Page 42 of 64
Command
Length
Reply
Description
yy = 37: LED 1 red
0 = Off
1 = On
(see chapter 8: Parameter description  Parameter no.
40)
yy = 38: LED 1 green
0 = Off
1 = On
(see chapter 8: Parameter description  Parameter no.
41)
yy = 39: Inching mode 2 acceleration type
0 = constant acceleration to final speed value
1 = incremental acceleration to final speed value
(see chapter 8: Parameter description  Parameter no.
31)
yy = 40: Protocol
0 = SIKONETZ5
1 = Service protocol
(see chapter 8: Parameter description  Parameter no.
34)
yy = 41: PIN change (see chapter 8: Parameter
description  Parameter no. 48)
yy = 42: Temporary key function enable
0 = Access as defined under Key function enable
1 = Access inverted as defined under Key function
enable
yy = 43: Displayed value of 2
nd
display line
0 = Set point
1 = Output stage temperature
2 = Control voltage
3 = Output stage voltage
4 = Battery voltage
5 = Motor current
6 = Actual position
7 = Actual rotational speed
(see chapter 8: Parameter description  Parameter no.
49)
yy = 44: Display divisor application (see chapter 8:
Parameter description  Parameter no. 74)
I
1/2
">"
Cancel current travel job in positioning mode
Motor remains in control state
Jyy
3/6
"0xhh>"
Read out error memory
yy = 00 number of errors in the error memory (see
chapter 8: Parameter description  Parameter no. 61)
yy = 01 Error 1 (see chapter 8: Parameter description
 Parameter no. 62)
yy = 02 Error 2 (see chapter 8: Parameter description
 Parameter no. 63)
