Service Protocol
AG05 Date: 15.06.2016 Art. No. 85677 Mod. status 139/16 Page 41 of 64
Command
Length
Reply
Description
yy = 15: Stop mode inching 2 (see chapter 8:
Parameter description  Parameter no. 25)
yy = 16: Inpos mode (see chapter 8: Parameter
description  Parameter no. 26)
yy = 17: Loop length
Spindle pitch = 0 -> increments
Spindle pitch > 0 -> 1/100 mm
(see chapter 8: Parameter description  Parameter no.
27)
yy = 18: Contouring error limit (see chapter 8:
Parameter description  Parameter no. 28)
yy = 19: reserved
yy = 20: reserved
yy = 21: reserved
yy = 22: reserved
yy = 23: reserved
yy = 24: Current limiting [%] (see chapter 8: Parameter
description  Parameter no. 29)
yy = 25: Baud rate RS485 (see chapter 8: Parameter
description  Parameter no. 33)
yy = 26: Bus Timeout (see chapter 8: Parameter
description  Parameter no. 35)
yy = 27: Inching 2 Offset (see chapter 8: Parameter
description  Parameter no. 30)
yy = 28: Key function enable
0 = all functions via key enabled
1 = all functions via key disabled
(see chapter 8: Parameter description  Parameter no.
38)
yy = 29: Key enable time (see chapter 8: Parameter
description  Parameter no. 37)
yy = 30: Display orientation (see chapter 8: Parameter
description  Parameter no. 45)
yy = 31: Display divisor (see chapter 8: Parameter
description  Parameter no. 43)
yy = 32: Display: Decimal places (see chapter 8:
Parameter description  Parameter no. 42)
yy = 33: Display: Direction indication function (see
chapter 8: Parameter description  Parameter no. 44)
yy = 34: reserved
yy = 35: reserved
yy = 36: LED 2 orange
0 = Off
1 = On
(see chapter 8: Parameter description  Parameter no.
39)
