Simplex 4010ES User Manual

4-1
Chapter 4
Supervisory Conditions
Introduction A Supervisory condition indicates that
• some part of the building’s fire protection system is disabled. An example of this is a sprinkler
tamper switch being activated due to a fire sprinkler control valve being closed.
• a lower priority initiating device (such as a duct smoke detector) has been triggered.
Depending on the system design, a Supervisory point can be:
• Latching. The panel must be reset to clear the Supervisory condition.
• Non-latching. The indicators (LED, buzzer, etc.) turn off automatically when the condition
clears.
This chapter describes using the Operator Interface Panel keys to investigate the details of the
supervisory condition.
In this Chapter Refer to the page number listed in this table for information on a specific topic.
Topic See Page #
Overview 4-2
Acknowledging Supervisory Conditions 4-3

Simplex 4010ES Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Operating Temperature	32°F to 120°F (0°C to 49°C)
Power Supply	120V AC or 240V AC
Zones	10
Communication Ports	RS-232, Ethernet
Signaling Line Circuits (SLCs)	2
Notification Appliance Circuits (NACs)	4
Max Notification Appliances	Varies based on NAC configuration and power supply
Communication Options	Cellular, Ethernet
Weight	30 lbs
Humidity Range	Up to 93% non-condensing
Certifications	UL, FM, CSFM, MEA
Network Capability	Yes
