Simplex 4010ES User Manual

6-8
Displaying and Clearing Historical Logs
Overview Historical logs provide a record of both the events that have occurred on the system and the actions
taken by an operator to manage those events. The system contains the following logs.
• Historical Alarm Log. Provides detailed information on each alarm, including time and date
stamp, that has occurred since the last time the logs were cleared.
• Historical Trouble Log. Provides detailed information on each trouble, including time and date
stamp, that has occurred since the last time the logs were cleared.
Displaying/Clearing
Historical Logs
1. Press the Menu key. Use the Next and Previous keys to scroll through the choices until the
“DISPLAY HISTORICAL ALARM LOG” or “DISPLAY HISTORICAL TROUBLE LOG”
choice is displayed.
2. Press ENTER to enter the log file.
3. Use the Next and Previous keys to scroll through the entries in the selected log. Press ENTER at
any time while in the log to clear all events.

Simplex 4010ES Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Operating Temperature	32°F to 120°F (0°C to 49°C)
Power Supply	120V AC or 240V AC
Zones	10
Communication Ports	RS-232, Ethernet
Signaling Line Circuits (SLCs)	2
Notification Appliance Circuits (NACs)	4
Max Notification Appliances	Varies based on NAC configuration and power supply
Communication Options	Cellular, Ethernet
Weight	30 lbs
Humidity Range	Up to 93% non-condensing
Certifications	UL, FM, CSFM, MEA
Network Capability	Yes
