Simplex 4010ES User Manual

7-2
Lamp Test / Tone Alert Test
Overview The Lamp Test key on the operator interface panel is used to determine local lamp failures within the
system. Lamps on the 4010ES operator interface panel illuminate along with the five function and
acknowledge LEDs.
The tone-alert (buzzer) can also be tested with the Lamp Test.
Performing a Lamp
Test
Do the following procedures to test for lamp failures.
1. Press the Lamp Test push-button. All LEDs should illuminate (lamps should stay illuminated as
long as the key is depressed).
2. If you find defective lamps/LEDs, contact your local SimplexGrinnell branch office.
Testing the Tone-
Alert
Holding the Lamp Test key for more than 3 seconds tests the tone-alert.

Simplex 4010ES Specifications

General

Control Panel Type	Addressable Fire Alarm Control Panel
Display	LCD
Operating Temperature	32°F to 120°F (0°C to 49°C)
Power Supply	120V AC or 240V AC
Zones	10
Communication Ports	RS-232, Ethernet
Signaling Line Circuits (SLCs)	2
Notification Appliance Circuits (NACs)	4
Max Notification Appliances	Varies based on NAC configuration and power supply
Communication Options	Cellular, Ethernet
Weight	30 lbs
Humidity Range	Up to 93% non-condensing
Certifications	UL, FM, CSFM, MEA
Network Capability	Yes
