2-23
Refer to the Figure 2.17 below to mount the display cards to the front of the expansion
box.
Figure 2-17. LED/Switch Card Mounting on a bay mounted door
(earlier style)
Continued on next page
Step 6. Installing LED/Switch Modules into Expansion Bays (4100ES),
Continued
Mounting
LED/Switch Modules
to the Expansion
Bay
#6 UNC NUTS
GROUND
CONNECTION
ADDITIONAL
LED/SWITCH
CONTROLLER
GROUND
CONNECTION
LOCKWASHERS
Controller assemblies
can only be installed
into these two slots
