Simplex 4100ES Installation & Maintenance

2-25
Figure 2-19. Assembling / Disassembling the LED Display Card
(pluggable LED version, only)
User interface wiring consists of connecting the LED/switch controller card to the
expansion bay’s power distribution interface (PDI), and connecting display cards to each
other. This section describes both procedures.
Continued on next page
Step 6. Installing LED/Switch Modules into Expansion Bays (4100ES),
Continued
Changing Display
Card LEDs,
(continued)
Interconnecting
Cards

Simplex 4100ES Specifications

General

Type	Fire Alarm Control Panel
Display	LCD
Battery Backup	Yes
Model	4100ES
Manufacturer	Simplex
Communication Protocol	Optional Ethernet
Signaling Line Circuits (SLCs)	Up to 10
Notification Appliance Circuits (NACs)	Up to 10
Agency Listings	UL, FM, CSFM, MEA
Max Relay Circuits	20
Communication Ports	Ethernet
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity	Up to 93% RH, non-condensing
