Simplicity LEGACY Series User Manual

13 - 1
13 Engine Removal & Installation
Table of Contents
SECTION CONTENTS
Exploded View Diagrams
Drive Shaft, Throttle/Choke, and Seal........................................ 13-2
Engine Group - 20HP & 25 HP Kohler Engine Models .............. 13-4
Engine Group - 20HP Kawasaki Engine Models........................ 13-6
Engine Group - 24.5 B&S Diesel Engine Models....................... 13-8
Radiator & Hose Group - 24.5 B&S Diesel Engine Models...... 13-10
Engine Removal & Installation -
20HP & 25 HP Kohler Engine Models
General .................................................................................... 13-12
Engine Removal....................................................................... 13-12
Engine Installation.................................................................... 13-16
Engine Removal & Installation -
20HP Kawasaki Engine Models
General .................................................................................... 13-20
Engine Removal....................................................................... 13-20
Engine Installation.................................................................... 13-24
Engine Removal & Installation -
24.5HP Briggs & Stratton Diesel Engine Models
General .................................................................................... 13-28
Engine Removal....................................................................... 13-28
Engine Installation.................................................................... 13-32
SECTION 13. ENGINE REMOVAL & INSTALL
Not for Reproduction

Simplicity LEGACY Series Specifications

General

Engine Brand	Briggs & Stratton
Transmission	Hydrostatic
Deck Type	Fabricated
Cruise Control	Yes
Cutting Width	52 in.
Turning Radius	18 inches
Cutting Height	1.5 - 4.5 in.
Deck Material	Steel
Warranty	3 years
