14 - 5
14 Hood, Dash, & Foot Rest Service
Diagrams
1 12 CAPSCREW, Hex Hd Whiz
2 2 MOULDING
3 1 SHIELD, Hood (Air-Cooled Models Only)
4 8 NUT, Hex Whiz
5 1 SHIELD, Inner Hood
6 4 NUT, Retainer
7 1 INSULATION, Headlight
8 1 PLATE, Headlight Shield
9 1 AIR DEFLECTOR, Headlight
10 1 INSULATION, LH Hood
11 1 INSULATION, RH Hood
Heat Shield (Gas Engine Models)
REF NO. QTY. DESCRIPTION
Not for Reproduction
