12 - 3
1 1 KNOB, Parking Brake
2 1 NUT, Hex
3 1 ROD, Parking Brake
4 1 CLIP, Rod
5 1 BRACKET, Parking Brake Pivot
6 1 CARRIAGE BOLT
7 1 SPACER
8 1 WASHER
9 1 NUT, Hex, Ctr Lock
10 1 ROD, Parking Brake
11 1 BRACKET, Parking Brake
12 1 SPACER
13 2 WASHER
14 1 SCREW, Taptite
15 1 SPACER
16 1 NUT, Hex, Nylon
17 1 SPRING, Extension
18 3 PIN, Cotter
19 3 WASHER, Plain
20 1 SPRING, Compression
21 1 BRAKE ROD ASSEMBLY
22 1 CAPSCREW, Hex
23 2 NUT, Hex, Nylon
24 1 BRAKE CALIPER ASSEMBLY (Includes Ref 25 thru 37)
25 2 CAPSCREW, Hex Hd
26 1 PAD, Brake, Outer
27 2 SPACER
28 2 SPRING, Compression
29 1 PAD, Brake, Inner
30 1 WASHER
31 1 BRACKET
32 1 BRACKET, Mounting
33 1 KLIP RING
34 1 WASHER
35 1 SPRING, Compression
36 2 NUT, Hex
37 2 LOCKWASHER
38 1 BRAKE, Disc
39 1 KEY, Woodruff
40 4 CAPSCREW, Hex Hd, Taptite
41 1 BRACKET
42 1 ROD, Brake
43 2 RIVET, Pop
44 1 ACTUATOR, Switch
45 1 STRAP
46 1 BRAKE ARM ASSEMBLY
47 1 BUSHING
48 2 WASHER
49 1 KLIP RING
50 2 SCREW, Taptite
51 1 LEVER, Brake
52 1 PAD, Brake Pedal
12 Brake System Service
Diagrams
Brake Control and Parking Brake Group (All Models)
REF NO. QTY. DESCRIPTION
