Simplicity LEGACY Series User Manual

14 - 1
14 Hood, Dash, & Foot Rest Service
Table of Contents
SECTION CONTENTS
DIAGRAMS
Hood, Dash, and Foot Rest Group ............................................ 14-2
Heat Shield (Gas Engine Models) ..............................................14-4
REMOVAL AND INSTALLATION
Hood Removal ........................................................................... 14-6
Hood Installation ........................................................................ 14-6
Hood Disassembly......................................................................14-7
Bumper Replacement .................................................................14-8
Dashboard Removal ...................................................................14-8
Dashboard Replacement ............................................................14-9
Tunnel Assembly Removal .......................................................14-10
Tunnel Assembly Replacement ................................................14-10
SECTION 14. HOOD, DASH, & FOOT REST SERVICE
Not for Reproduction

Simplicity LEGACY Series Specifications

General

Engine Brand	Briggs & Stratton
Transmission	Hydrostatic
Deck Type	Fabricated
Cruise Control	Yes
Cutting Width	52 in.
Turning Radius	18 inches
Cutting Height	1.5 - 4.5 in.
Deck Material	Steel
Warranty	3 years
