15 - 5
15 Seat Deck & Fuel Tank Service
Diagrams
1 1 TANK, Fuel
2 1 CAP, Fuel Tank
3 2 CLAMP, Hose
4 2 ELBOW, Fuel Tank
5 1 BUSHING, Fuel Tank Seal
6 5 CAPSCREW
7 5 LOCKWASHER
8 1 SENDER, Fuel Level
9 1 GASKET, Fuel Tank
10 2 SUPPORT, Fuel Tank
11 4 CAPSCREW, Hex Hd
Fuel Tank Group (All Models)
REF NO. QTY. DESCRIPTION
Not for Reproduction
