18 Mower Deck Service
48" Mower Deck – Housing, Covers & Gauge Wheel Group
REF. QTY. DESCRIPTION
1 1 HOUSING, 48 Mower Deck
2 2 ARM, Adjusting
3 6 NUT, Hex Jam, 5/8-18
4 4 WASHER, 5/8
5 2 BOLT, Shoulder, 1/2 x 1.53 - 3/8-16
6 2 TRUNNION
7 2 CHAIN, Lift
8 2 TUBE, Shrink Wrap
9 2 NUT, Hex Flange, Centerlock, 3/8-16
10 1 SUPPORT ASSEMBLY, 48 Mower Deck
11 8 NUT, Hex, 3/8-16
12 8 LOCKWASHER, 3/8
13 6 WASHER, 3/8
14 1 COVER, RH, 48 Mower Deck
15 1 PLUG, Cover
16 1 COVER, LH, 48 Mower Deck
17 10 CAPSCREW, Taptite, 1/4-20 x 3/8
18 4 CAPSCREW, Taptite, 5/16-18 x 5/8
19 4 CAPSCREW, Taptite, 5/16-18 x 1
20 4 KLIPRING, 5/8
21 4 WASHER, Plain, 5/8
22 2 WHEEL, Gauge
23 2 SPINDLE, Gauge Wheel
24 2 SPRING, Compression
25 1 BRACKET ASSEMBLY, LH Gauge
26 1 BRACKET ASSEMBLY, RH Gauge
27 6 CAPSCREW, Hex Hd, 3/8-16 x 1
48" Mower Deck – Housing, Covers & Gauge Wheel Group
