18 - 9
18 Mower Deck Service
48" Mower Roller Bar Group (SN 60000 and above)
REF. QTY. DESCRIPTION
1 1 ROCKER SHAFT ASSEMBLY
2 2 CARRIAGE BOLT, 3/8-16 x 1-3/4
3 2 WASHER, 3/8
4 12 CARRIAGE BOLT, 3/8-16 x 1
5 12 LOCKWASHER, 3/8
6 12 NUT, Hex, Full, 3/8-16
7 4 WASHER, Plain, 3/8
8 1 BRACKET, Roller, RH
9 2 SPACER, Long
10 13 WASHER, 1.0
11 2 ROLLER, Outer
12 1 PIN, Cotter
13 2 BOLT, Shoulder
14 2 WASHER, 1/2 x 1-1/4
15 2 SLIDE
16 2 NUT, Adjuster, Eccentric
17 1 BAR & SHAFT ASSEMBLY, Roller
18 7 ROLLER, Inner
19 14 BUSHING, Roller
20 1 SPACER, Short
21 1 BAR ASSEMBLY, Roller, RH
22 1 SET SCREW, Sqr Hd, 5/16-18 x 1/2
23 1 BRACKET, Roller, LH
24 1 DECAL, Cutting Height Indicator
25 1 PLATE, Height Indicator
26 1 CAPSCREW, Hex Hd, Taptite, 1/4-20 x 3/8
27 1 ROD, Indicator
28 1 CAPSCREW, Hex Hd, Taptite, 5/16-18 x 1/2
29 2 CARRIAGE BOLT, 3/8-16 x 2-1/4
30 2 SPACER
31 2 STRAP
32 1 KIT, 48" Mower Slide Wheel (Includes Ref 32-39)
33 1 E-RING, 1/2
34 1 WASHER, Flat, 1/2 x 7/8
35 1 WHEEL, Slide
36 1 BAR ASSEMBLY, Wheel
37 1 HAIRPIN
38 1 HITCH PIN, 3/8
39 1 CAPSCREW, Hex Hd, 3/8-16 x 1-1/2
40 1 NUT, Hex, Nylon Lock, 3/8-16
48" Mower Roller bar Group (SN 60000 and above)
