18 - 15
18 Mower Deck Service
48" Mower Deflector and Stone Guard Group
REF. QTY. DESCRIPTION
1 7 NUT, Hex, 3/8-16
2 7 LOCKWASHER, 3/8
3 1 BRACKET
4 2 CAPSCREW, Hex Hd, 3/8-16 x 1
5 1 DEFLECTOR ASSEMBLY
6 5 CARRIAGE BOLT, 3/8-16 x 1
7 1 STONE GUARD
8 1 ROD, Hinge
9 1 WASHER, Plain
10 1 SPRING, Torsion
48" Mower Deflector and Stone Guard Group
