Simplicity LEGACY Series User Manual

18 - 23
18 Mower Deck Service
54" Mower Roller Bar Group
REF. QTY. DESCRIPTION
1 14 WASHER, 1"
2 2 ROLLER
3 1 SPACER, Short
4 2 PIN, Cotter, 3/16 x 1-1/2
5 1 ASSEMBLY, Roller Shaft & Bar
6 9 ASSEMBLY, Roller
7 2 NUT, Adjuster, Eccentric
8 4 LOCKWASHER, 3/8
9 4 NUT, 3/8-16
10 1 SCREW, Set, Sq Hd, 5/16-18 x 1/2
11 1 ASSEMBLY, Roller Bar
12 1 ROLLER, Short
13 2 BOLT, Shoulder
14 2 WASHER, 1/2 x 1-1/4
15 2 SLIDE
16 2 BOLT, Carriage, 3/8-16 x 1-1/2, Grade 5
17 7 CAPSCREW, Hex Hd, Taptite, 5/16-18 x 3/4
18 4 STRAP
19 1 ASSEMBLY, Rocker Shaft & Lever
20 1 CAPSCREW, Hex Hd, Taptite, 5/16-18 x 7/8
21 1 INDICATOR, Height
22 3 CAPSCREW, Hex Hd, Taptite, 5/16-18 x 1/2
23 1 BRACKET, Height of Cut
54" Mower Roller Bar Group
Not for Reproduction

Simplicity LEGACY Series Specifications

General

Engine Brand	Briggs & Stratton
Transmission	Hydrostatic
Deck Type	Fabricated
Cruise Control	Yes
Cutting Width	52 in.
Turning Radius	18 inches
Cutting Height	1.5 - 4.5 in.
Deck Material	Steel
Warranty	3 years
