18 Mower Deck Service
60" Mower Baffle & Inner Roller Group
REF. QTY. DESCRIPTION
1 2 NUT, Hex Centerlock, 5/16-18
2 1 BRACKET & SHAFT ASSEMBLY, Inner
3 4 ROLLER ASSEMBLY
4 2 WASHER
5 1 SPACER
6 4 NUT, Hex, 5/16
7 4 LOCKWASHER, 5/16
8 1 BRACKET, Inner, LH
9 4 CARRIAGE BOLT, 5/16-18 x 3/4
10 2 CAPSCREW, Taptite, 5/16-18 x 5/16
11 1 BAFFLE, Discharge
12 2 CARRIAGE BOLT, 5/16-18 x 3/4
13 2 LOCKWASHER, 5/16
14 2 NUT, Hex,5/16-18
15 1 BAFFLE ASSEMBLY, Front
16 9 NUT, Hex, 3/8-16
17 9 LOCKWASHER, 3/8
18 9 CARRIAGE BOLT, 3/8-16 x 1.0
19 1 BRACKET, Mower
20 1 BAFFLE ASSEMBLY
60" Mower Baffle & Inner Roller Group
