18 - 37
18 Mower Deck Service
60" Mower Height Adjust & Hitch Group
REF. QTY. DESCRIPTION
1 1 MOTOR, Electric Cutting Height Adjust
2 2 CAPSCREW, Hex Hd, Taptite, 5/16-18 x 7/8
3 1 BRACKET, Motor Mounting
4 3 LOCKWASHER, 1/4
5 3 CAPSCREW, Hex Hd, 1/4-20 x 3/4
6 1 ADAPTER, Motor
7 1 WASHER, Plain, 1/4
8 1 NUT, Hex Centerlock, 1/4-20
9 1 ROLL PIN, 3/16 x 1 3/4
10 1 HUB, Shaft
11 1 WASHER, Nylon
12 1 BEARING, Thrust
13 1 SHAFT ASSEMBLY
14 1 NUT, Hex, 1/2-13
15 1 LOCKWASHER, 1/2
16 1 LEVER
17 1 COVER, Rod
18 1 FITTING, Lube
19 1 TRUNNION
20 1 CARRIAGE BOLT, 1/2-13 x 2 1/2
21 1 SPACER
22 4 NUT, Hex Nylon Lock, 5/16-18
23 4 WASHER, Plain, 5/16
24 2 U-BOLT, Clamp
25 1 CLAMP
26 1 CAPSCREW, Hex Hd, Taptite, 5/16-18 x 1/2
27 1 COVER, Motor
28 1 HARNESS, Mower lift
29 2 NUT, Hex Nylon lock, 3/8-16
30 2 SPACER
31 2 WASHER, Plain, 3/8
32 2 CAPSCREW, Hex Hd, 3/8-16 x 1 1/2
33 2 RETAINING RING, 5/8
34 4 WASHER, 5/8 (* QTY. 4 on units with SN prior to 60000)
35 1 BRACKET ASSEMBLY, Front Mower Hitch
36 1 ROD, Latch
37 3 PIN, Safety
38 2 PIN, Hitch
39 1 HITCH ASSEMBLY
40 2 SPACER
41 1 SHAFT, Hitch
42* 1 BRACKET, Front Mower Hitch
Footnotes:
* If replacing Bracket {Ref 42} on units prior to SN 60000, order Bracket Assembly {Ref 35}. Spacer {Ref 40} and
Shaft {Ref 41} are NO LONGER required as these are integral to the replacement bracket.
60" Mower Height Adjust & Hitch Group
