18 - 45
18 Mower Deck Service
Gearbox – Service Parts
REF. QTY. DESCRIPTION
1 12 CAPSCREW, Hex Hd, Whizlock, 5/16-18 x 3/4
2* 2 CAP, Thru
3 A/R GASKET, 0.015 (Replace with Gasket of Identical Thickness)
3 A/R GASKET, 0.005 (Replace with Gasket of Identical Thickness)
3 A/R GASKET, 0.003 (Replace with Gasket of Identical Thickness)
4 2 SEAL, Shaft, 1 x 1-1/2 x 5/16
5* 3 BEARING RACE, Cup
6* 3 BEARING, Cone
7* 1 SHAFT
8* 1 GEAR
9* 1 BEARING, Cone
10* 1 BEARING RACE, Cup
11 4 PLUG, Pipe, Hex Socket Head
12* 1 HOUSING, Gearbox
13* 1 GEAR
14* 1 SHAFT
15* 1 CAP, Blank
16* 1 SPACER (Early Models Only)
Footnotes:
* If any of these parts need to be replaced, replace the complete gearbox assembly.
Note: 54" Gearbox is serviced as an assembly only.
Gearbox – Service Parts
