Simplicity LEGACY Series User Manual

19 - 1
19 Implement Lift Service
Table of Contents
SECTION CONTENTS
Exploded View Diagrams
Implement Lift Group (Gas Engine Models) .............................. 19-2
Implement Lift Group (Diesel Engine Models) ........................... 19-4
Replacement
General ...................................................................................... 19-6
Lift Control Valve Replacement ................................................. 19-6
Lift Pedal Assembly Replacement ............................................. 19-7
Lift Shaft Assembly Replacement.............................................. 19-8
Lift Cylinder Replacement.......................................................... 19-8
SECTION 19. IMPLEMENT LIFT SERVICE
Not for Reproduction

Simplicity LEGACY Series Specifications

General

Engine Brand	Briggs & Stratton
Transmission	Hydrostatic
Deck Type	Fabricated
Cruise Control	Yes
Cutting Width	52 in.
Turning Radius	18 inches
Cutting Height	1.5 - 4.5 in.
Deck Material	Steel
Warranty	3 years
