20 Power Steering Unit Service
Exploded View Diagram
20 - 2
Figure 1. Power Steering Control Unit (Exploded View Diagram)
Gerotor
O-ring
Seal
Ring
O-ring
Seal
End
Cap
Cap
Screw
(7)
Dust
Seal
Housing
Quad
Seal
Thrust
Bearing
Bearing Race (2)
Check
Ball
O-ring
Plug
Wear
Plate
O-ring
Drive
Spacer
Sleeve
Pin
Centering
Springs
Spring
Retaining
Ring
O-ring
Seal
Spool
