7 - 7
7 Electrical System Service
Liquid-Cooled Engine Models
1 1 BEZEL, Headlight
2 2 BULB, Headlight, Halogen
3 1 HARNESS, Headlight
4 1 CLIP
57 TIE
6 2 NUT, KEPS Lock
7 1 SWITCH, Interlock (NO/NO)
8 2 CAPSCREW
9 1 HARNESS, Main
10 1 SWITCH, Mower Height Adjust
11 1 SWITCH & KEY ASSEMBLY (Includes Ref 12 thru 15)
12 1 KEYS (Set of 2)
13 1 COVER, Key Switch
14 1 NUT, Hex Flange
15 1 WASHER, Internal Tooth
16 1 CABLE, Battery to Starter
17 1 LOCKWASHER
18 1 NUT, Hex Jam
19 1 COVER, Starter Terminal
20 1 COVER, Positive Battery Terminal
21 1 CABLE, Battery to Ground
22 1 BATTERY
23 2 ROD, Battery Hold-Down
24 1 BRACKET, Battery
25 2 NUT, Hex, Nylon Lock
26 1 LOCKWASHER
27 1 CAPSCREW
28 1 HARNESS, Power Outlet
29 1 CIRCUIT BREAKER
30 1 INSTRUMENT PANEL
31 8 BULB, Instrument Panel
32 1 SWITCH, Headlights
33 1 SWITCH, Front PTO
34 1 CLIP
Upper Wiring Harness (Liquid-Cooled Engine Models)
REF NO. QTY. DESCRIPTION
To Next Page
