Operation
20220596G 35
MAGN = Magnetic compass (or Simrad RFC35 Fluxgate
Compass. (See Note)
FLUXG = Non-Simrad fluxgate compass
GYRO = Simrad gyrocompass
NMEA = NMEA compass
Note ! It is necessary to select the correct compass and Nav. source to
make the autopilot operate.
When using the PORT or STBD buttons in automatic mode you
are changing the set course in 1° increments. If you prefer the
increments to be 10° each press, proceed as per below:
Course adjust
SYSTEM DATA
NMEA DATA
Select Course adjust using the PORT or STBD button. Turn the
rotary knob to display the setting
Course adjust
1°
The default value is 1° which is the preferred setting. Select 10°
if you want to make major course changes in 10° steps with the
buttons and fine tune the set course with the rotary knob.
System data and NMEA data found in this menu are test
functions to analyse data processed by the autopilot. (See
Trouble shooting page 113).
Except when NMEA data or System data is displayed, the menu
will disappear after 30 seconds if no key is pressed. It will
disappear immediately if any mode key (STBY, AUTO or
NAV/WIND) is pressed.
