118 | Optional equipment
8.2 S35 Steering Lever (NFU)
S35 has spring loaded return to mid-position. A push
button with light indicator is used for mode selection
similar to the R3000X Remote Control.
Alternatively S35 can be used as a conventional NFU
lever without mode selection.
Operation
Refer to the operation of the R3000X in the previous
chapter. On S35 you move the lever to right or left
instead of using keys.
8.3 JS10 Joystick (NFU)
The JS10 Joystick is a Non Follow-up steering lever
designed for indoor and outdoor console mount. It has
a spring-loaded return-to-mid-position and is equipped
with 10 m (33’) of cable and installation hardware.
Operation
JS10 has no mode change feature. The rudder will move
for as long as the lever is held in left (Port) or right
(Starboard) position.
8.4 AP28 with MSD50 Stern Drive unit
The information in this chapter only applies if your
autopilot is driving a Simrad MSD50 Stern Drive.
The MSD50 Stern drive needs a zero point setting after the
autopilot has been turned on. Refer to the MSD50 manual
for further information.
