Simrad AP28 User Manual

8 | System description
1.2 System components
12/24V Motor supply
Drive unit
Multijoiner
Compass
5,5 m
5 m
RF25 Rudder Feedback
12V SimNet supply
(SimNet cable without terminator)
Autopilot
Computer
Non SimNet
SimNet
Termination
plug
AP28
Control Unit
PWR
NAV WI N DTURN
STBY
DRIFT
NO-
AUTO
MENU
Figure 1-1 AP28 Basic system layout
1.3 AP28 Control Unit
PWR
NAV WI N DTURN
STBY
DRIFT
NO-
AUTO
MENU
A compact autopilot control for panel,
bulkhead or bracket mounting. A multifunction
LCD display with two-color backlighting
presents readout of autopilot and navigation
data, tactile keys, dedicated mode keys and
rotary course knob provide simple and precise
operation. It has two SimNet connectors for
system interconnection and control, expansion
and data sharing with other Simrad products.
A NMEA2000 Adapter Cable is available for
interface through a SimNet port.
