16 | Operation
b The Up/Down softkeys to increase/decrease
the light level by one step
c The Day/Night softkey to toggle between day
and night profiles
If no adjustment is performed within 3 seconds, the Light
level overlay window will close.
For contrast and day/night settings, refer to page
60.
2.4 Standby mode
STBY mode is the mode that is used when steering the
boat at the helm.
Display information:
• Standby mode
• Current heading 345°M
• Compass source: RC42
• Rudder angle 01° to stbd.
See page
80 about VRF.
Power steering (NFU)
In Standby mode, press any of the PORT or STBD keys.
The Non Follow-up (NFU) display is presented and the
rudder will move as long as the key is pressed.
Activates PORT
rudder command
Activates STBD
rudder command
When a NFU steering lever or remote control is operated,
other control units show (inactive). Refer to section 8
for operation of NFU steering levers or remote controls.
