Simrad GC80 Compact MK2 - Page 104

Simrad GC80/85 Compact MK2 Gyro Compass
988-12718-003 104
SWITCH DEFAULT FUNCTION DESCRIPTION
S2-8 OFF
System select
information contact
OFF = No ON = Yes
S3-1 OFF Timer startup OFF = No ON = Yes
S3-2 OFF
Talker ID of “ROT”
sentence
OFF = “HE” ON = “TI”
S3-3 ON
Not used -
S3-4 OFF
S3-5 OFF
Ban or permission of a
“ROT” sentence output
Valid at the time of external sensor (standard)
selection.
OFF = Disabled ON = Enabled
S3-6 ON For Simrad use
OFF = Not used
ON = Simrad GC type (80 or 85) shown in
display at start-up according to S1-2
setting.
S3-7 OFF Not used -
S3-8 OFF
External buzzer
stop/Gyro Running
Contact
OFF = External buzzer stop disabled, Gyro
Running Contact enabled
ON = External buzzer stop enabled
S4-1 OFF
Do not touch -
S4-2 OFF
S4-3 -
S4-4 OFF
Alarm detection time for
Main Power Fail/Power
Unit Fail
OFF = 300 ms ON = 2 sec
S4-5
ON
(THS)
Able/Disable for THS
sentence output
OFF = Disable to output
ON = Enable to output
S4-6 OFF Do not touch -
