DIP SWITCH SETTINGS
107 988-12718-003
JUMPER DEFAULT FUNCTION DESCRIPTION
J9
(3TX)
3-4 short
Output port: “3TX”
1-2 short = IEC61162-2 ed.1 or TOKIMEC version
3-4 short = IEC61162-1 ed.4
(ref. page 13)
NOTE: Never use both jumpers at the same
time!
J10
(4TX)
3-4 short
Output port: “4TX”
1-2 short = IEC61162-2 ed.1 or TOKIMEC version
3-4 short = IEC61162-1 ed.4
(ref. page 13)
NOTE: Never use both jumpers at the same
time!
J11
(GPSPOL)
1-2 short
Polarity for “GPS” signal
setting
Input port: “GRX”
1-2 short = Standard
3-4 short = Reversed polarity
NOTE: If no signal is received with 1-2 short,
set 3-4 to short.
NOTE: Never use both jumpers at the same
time!
J12
(LOGPOL)
1-2 short
Polarity of “LOG” signal
setting
Output port: “LOGPOL”
1-2 short = Standard
3-4 short = Reversed polarity
NOTE: Never use both jumpers at the same
time!
J13
(ESPOL)
1-2 short
Polarity of the “external
heading sensor” signal
setting
Input port: “ESPOL”
1-2 short = Standard
3-4 short = Reversed polarity
NOTE: Never use both jumpers at the same
time!
