Simrad GC80 Compact MK2 - Page 96

Simrad GC80/85 Compact MK2 Gyro Compass
988-12718-003 96
TB1-2
PIN NO NAME DETAILS
25 BZSP+
Pendulum/Remote buzzer stop signal input
26 BZSP-
27 EACK+
External alarm acknowledge signal input
28 EACK-
29 1TX+ Serial signal output (+)
30 1TX- Serial signal output (-)
31 1TSC Serial signal output (GND)
32 1R24- Serial repeater power supply (24 V DC GND)
33 1R24+ Serial repeater power supply (24 V DC)
34 2TX+ Serial signal output (+)
35 2TX- Serial signal output (-)
36 2TSC Serial signal output (GND)
37 2R24- Serial repeater power supply (24 V DC GND)
38 2R24+ Serial repeater power supply (24 V DC)
39 3TX+ Serial signal output (+)
40 3TX- Serial signal output (-)
41 3TSC Serial signal output (GND)
42 3R24- Serial repeater power supply (24 V DC GND)
43 3R24+ Serial repeater power supply (24 V DC)
44 4TX+ Serial signal output (+)
45 4TX- Serial signal output (-)
46 4TSC Serial signal output (GND)
47 4R24- Serial repeater power supply (24 V DC GND)
48 4R24+ Serial repeater power supply (24 V DC)
