TERMINAL LAYOUT
97 988-12718-003
TB1-3
PIN NO NAME DETAILS
49 GRX+
GPS serial signal input
50 GRX-
51 GSC Serial signal input (GND)
52 LRX+
Speed Log serial signal input
53 LRX-
54 LSC Serial signal input (GND)
55 ESRX+
External sensor serial signal input
56 ESRX-
57 ESC External sensor serial signal GND
58 SL+
Input dry contact of Speed Log 200/400 p.p.n.m.
59 SL-
60 RNCN+
Running contact/remote buzzer stop output
61 RNCN-
62 GCCN+
Gyro select signal input (External switch)
63 GCCN-
64 ECCN+
External sensor select signal input (External switch)
65 ECCN-
66 PF
Power unit alarm input
67 POC
68 POV
69 PC Power unit alarm input (GND)
70 SWV
Not used
71 SW+
72 SWC
