Simrad - HH36 Installation and Operation Instructions 11
2-1 Keys/Controls and functions
PWR/LOCK/EXIT PWR: To turn the unit on and o, press and hold down PWR /
/ EXIT (red key) for more than 2 seconds and release.
LOCK: The keylock, locks and unlocks keypad. Press PWR /
/ EXIT (red key) for 1 second and release. A key icon will
appear on screen to indicate whether keylock is on or o.
EXIT: Also used to EXIT some menu items while in DSC mode.
Short press PWR / / EXIT (red key) for 1 second and release.
VOL Volume Adjustment - located on the side of the radio. Press
to increase or press to decrease until a comfortable volume is
reached.
SQL / Squelch or Threshold Level - located on the central control dial.
Sets the threshold level for the minimum receiver signal. 16
steps available.
CH / Channel select - located on the central control dial. Press to
select a higher channel or press to select a lower channel.
16/9 Priority Channel. Press to cancel all other modes (except for
when in DSC mode) and to tune into the priority channel. Press
again to return to your original channel. To make Channel 09
the default instead, hold down 16/9 until a beep sounds and 09
is displayed (US only).
CH / Channel Select. The current channel is shown on the screen in
BIG digits with the channel description information below the
channel number.
Press CH / to step through the available channels one at a
time, or hold down to scroll quickly through all the available
channels. See Appendix B for a listing of channel charts.
Alphanumeric Entry. This key can also be used for menu
selection and alphanumeric entry. Press CH / to scroll the
cursor up or down menu options when navigating menus.
When editing an item that contains only numbers, press - CH
to count through the numbers or hold down to scroll through
quickly.
To enter a character, press CH to step through the alphabet or
hold down to scroll through quickly.
PTT Push To Talk. Push to start transmitting then talk into the mic.
