Simrad - HH36 Installation and Operation Instructions 65
1. Plug in the AC/DC wall charger- check the voltage is correct for your wall charger.
2. Connect the charging wire into the charging socket on the cradle charger.
3. Insert the entire radio or the separated battery pack into the cradle charger. The
metal charge contacts on the radio will contact the mating prongs in the charger to
transfer the charging current.
4. Observe that the red light on the front of the charger glows to indicate that the
battery pack is properly seated and the charger is operating.
5. Allow the battery to charge for about 2.5 to 3 hours before use. The light will change
back to green when the battery is fully charged.
CAUTION
To maximise battery life: remove the battery from the charger after approximately
3.5 hours. Overcharging batteries may result in damage to both the battery pack and
radio.
7-1-3 GPS connector
NMEA connector
Connect to NMEA
0183 port on MFD
MARK
MOB
GOTO
MENU
PAGES
STBY
IN
MOB
OUT
AUTO
SIMRAD
NSS 7
P
U
S
H
T
O
E
N
T
E
R
