Simrad HH36 User Manual

Simrad - HH36 Installation and Operation Instructions 25
GO
HOME
►YES
NO
1. Select WAYPOINT and press ENTER.
2. The cursor is at WP LIST, press ENTER. The cursor is at NEW WP, scroll down to the
waypoint to use as the route then press ENTER.
3. The cursor is at GO, push ENTER and enter the navigation mode. The waypoint is set
as your next destination.
4-2 Backlight adjustment
1. Select BACKLIGHT and press ENTER. There are 8 backlight levels.
2. SQ / to adjust the setting. Press ENTER to conrm the setting and return to the
MENU SELECT.
MENU SELECT
WAYPOINT
►BACKLIGHT
LAMP ▼
BACKLIGHT
■ ■ ■ ■
LO HI
4-3 Lamp timer
1. Select LAMP and press ENTER. There are 4 timer settings: Always on, 5s, 15s, 30s
(default).
2. Press CH / to adjust the setting. Press ENTER to conrm the setting and return to
the MENU SELECT.
MENU SELECT
WAYPOINT
BACKLIGHT
►LAMP ▼
LAMP TIMEOUT
►ALWAYS ON
5 SECOND
15 SECOND
