Simrad - HH36 Installation and Operation Instructions 19
• 16/9 Return to normal mode and go to 16/9
• NAV Return to normal mode
• GO Reset the cross track error (XTE)
• SQL Go to WP select Mode
• SQL Go to Plotter Mode
• Other key Error beep.
3-10 WP select mode
WP LIST 13
CAMP 1 MOB 1
CAMP 2 MOB 2
CAMP 3 MOB 3
DOCK 1 PARK 1
DOCK 2 PARK 2
EXIT ENTER
• CH / Page up down the list
• SQL Go to Plotter Mode
• SQL Returns to Navigation Mode.
Note: During WP Select Mode, press ENTER right-key to ash the rst WP, then press
CH / to select next WP, press ENTER right-key again to set the WP as your next
destination and enter navigation mode.
3-11 Plotter mode
During plotter mode:
• Softkey It will zoom in/out the circle to see more/less area
• SQL Go to Navigation Mode
• SQL Go to WP select Mode
