© Feb. 2023 20 TB20J Plus Operation Manual
TECHNICAL PARAMETERS
Table 4-1 TB20J Plus specifications(Continued)
ITEM
TB20J Plus (METRIC) TB660J Plus (IMPERIAL)
Max allowable tilt angle
5°
Turning radius (inside/outside)
2.4m/5.55m 7ft 10in/18ft 3in
Turntable tail-swing
1.45m 4ft 9in
Tire (spec/type)
355/55D625 (foam-filled)
36×14-20 (solid)
Max. operating noise level
82dB
IP rating
IP65
Max total vibration value of the
platform
2.5m/s²
Max root-mean-square value of the
weighted acceleration of the entire
machine
0.5m/s²
POWER
Drive×steer 4WD×2WS
Engine
(power/rpm/spec/brand/emission
standard)
43kW/2500rpm/QSF2.8t3NA60/Cummins/China T3
36.4kW/2600rpm/D2.9 L4/Deutz/EU T5
36.4kW/2600rpm/D2.9 L4 T4f/Deutz/EPA T4
55.4kW/2400rpm/TD2011 L04i/Deutz T3
36.8kW/2500rpm/WP3.2/Weichai/China T4
36.8kW/2200rpm/YCF3050/Yuchai T4
Hydraulic tank capacity
180L
39.6gal (UK)/47.6gal (US)
Oil capacity of hydraulic tank
150L
33.0gal (UK)/39.6gal (US)
Diesel tank capacity
160L
35.2gal (UK)/42.3gal (US)
Hydraulic system pressure
28MPa
4061psi
Battery (voltage, capacity)
12V, 220Ah
System voltage
12VDC
Control voltage
12VDC
WEIGHT
Gross weight 11900kg
26235lb
GROUND BEARING DATA
Max. tire load
6740kg
14859lb
Pressure against ground
674kPa
97.8psi
ENVIRONMENT
Max. allowable side force
(restricted/unrestricted)
400N 90lbf
Max. allowable wind speed
12.5m/s 28mph
Max. allowable altitude 1000m 3280ft
Allowable ambient temperature -10℃～40℃ 14℉～104℉
