OPTIONS
TB20J Plus Operation Manual
67
© Feb. 2023
Disassemble the anti-pinch device in the reverse order
of the installation instructions.
Instructions for Use
1. Under normal circumstances, the foldable plates on
both sides of support #2 will be attracted by the
magnets below.
2. Press down the railing of support #2 so that the fold-
able plates on both sides detach from the magnets
and cock up, and the travel switch will be discon-
nected, the left and right strobe lights will flash, and
all functions on the platform controller will be
disabled.
3. Depress the foot switch while flipping the release
switch on the platform controller, and the boom can
be retracted and lowered, and the turntable can ro-
tate slowly.
4. To enable the boom extending and elevating func-
tions, lift the railing of support #2 up until the fold-
able plates on both sides are re-attracted by the
magnets and the strobe light goes out.
11.2 PLATFORM PIPE SUPPORT
DEVICE
Self-propelled boom-supported elevating work platforms
are designed to transport people, tools and materials to
aerial workplaces. When pipes need to be transported
to aerial workplaces, they can be placed on the pipe
support device and then transported after secured to the
device.
